Developed by Beijing Dorland System Control Technology Co., LTD., the industrial explosion-proof Pad XPad_07 5G adopted advanced technology with intrinsically safe circuit, 8.0” touch screen and 5 Megapixel (Front Camera) 13 Megapixel (Rear Camera with Auto Focus) camera. Its waterproof and dustproof performance can meet the IP67 standards; In addition, built-in GALILEO /GLONASS /BEIDOU /GPS positioning system, elevation measurement, compass, and other functions suitable for outdoor construction and pipeline inspection. It can also cooperate with OA office system, checking positioning system and data acquisition system etc. Especially it is used in dangerous environment of the explosion, such as petroleum, chemical, pharmaceutical, oil depot, tank farm as well as the dangerous sites with combustible and explosive gas. It is convenient for users to dispatch communicate timely.
Ex-Marking：
Ex ib IIC T4 Gb / Ex ib D21 T130°C
Protection Grade:
IP67
Certification No.：
CCRI 23.2951x
OS:
Android 12.0
Touch Lens:
Capacitive Touch screen
LCD Parameter:
TFT,8inch, 1280*800/1920*1200 resolution Touchable hd large screen, visible with strong light
Wifi6-Ready, 802.11ac, a/b/g/n, Frequency 2.4GHz/5GHz
NFC:
Yes
G-Sensor:
Yes
Gyroscope:
Yes
Light Sensor:
Yes
E-compass:
Yes
GPS:
uBlox GPS GALILEO/GLONASS/BEIDOU/GPS
