| Ex-mark: | Ex ib IIC T4 Gb / Ex ib IIIC T130℃ Db |
| Certificate No.: | SYEx24.0286X |
| IP Grade: | IP65 |
| Sensor type: | Non cooled detectors |
| Response band: | 8-14 μ M |
| NETD (Noise Equivalent Temperature Difference): | <50 mk (@ 25 ℃, F #=1.0) |
| Maximum image size: | 256 x 192 |
| Thermal imaging lens focal length: | 3.5 mm |
| Minimum imaging distance: | 0.3 m |
| Field of view angle: | 50 ° x 37.5 ° |
| Number doubling: | 1. x~4. x, with a minimum change of 0.1. x |
| Frame rate: | 25 Hz |
| Pixel size: | 12 μm |
| F-value: | F1.1 |
| Temperature measurement range: | -20 ℃~400 ℃ |
| Precision: | ± 2 ℃ or ± 2%, take the maximum value |
| Spatial resolution (IFOV): | 3.43 mrad |
| Maximum image size for visible light: | 3264 x 2448 |
| Image resolution: | Configurable: 2 MP, 5 MP, 8 MP |
| Video resolution: | 640 × 480 |
| Display: | 3.5 "LCD capacitive touch screen 640 × 480 |
| Image mode: | Supports 7 pseudo color modes such as rainbow and iron red |
| Screen display mode: | Visible light, thermal imaging, dual light fusion, picture in picture |
| Temperature measurement rules: | Supports hotspots, cold spots, and center points |
| UVC screen projection: | support |
| Battery capacity: | 2100mAh |
| Bluetooth/WIFI: | support |
| Photo/Video: | Thermal imaging, visible light, dual light fusion, picture in picture |
| Lighting: | support |
| Text comments: | support |
| Interface language: | Default Chinese, English requires special customization |
| Storage: | 16GB |
| Hardware interface: | Type-C |
